Genie GS-3369 Scissor Lift

38 ft 8 in Working Height
1,000 lb Platform Capacity
DC or Diesel Power
Full-Height Drive Capability
5 ft Slide-Out Extension Deck

Documents

Product Documents

Aerial Lift Information

Videos

The Genie GS-3369 rough terrain scissor lift gives operations teams a stable, high-capacity way to work at height across demanding indoor and outdoor jobsites. With a 38 ft 8 in working height, 1,000 lb platform capacity, full-height drive capability, and a 5 ft slide-out extension deck, it helps crews move people, tools, and materials efficiently without frequent repositioning. Available in DC electric and diesel RT configurations, the GS-3369 can support a range of applications from emissions-sensitive facility work to uneven outdoor terrain. As a Genie equipment dealer, Conger can help you compare configurations, options, and availability to choose the right lift for your operation.

Model Numbers: GS-3369 RT | GS-3369 DC

Additional Information

Condition	New
Brand	Genie
MEWP Type	Scissor Lift
Power	Electric, Engine
MEWP Lift Height	26 – 40ft
MEWP Capacity	501 – 1,000 lbs

Available in electric DC and diesel RT configurations to match indoor/outdoor, emissions-sensitive, and demanding outdoor applications.
Provides a 38 ft 8 in maximum working height with full-height drive capability.
Offers a 1,000 lb platform capacity to support operators, tools, and materials.
Built for rough terrain performance with a full-time oscillating axle that helps maintain traction on uneven ground.
Large 5 ft slide-out extension deck increases platform reach and work area.
Compact 5 ft 9 in machine width helps improve access around jobsites.
DC model delivers emissions-free performance for indoor and outdoor use on firm, level surfaces.
RT model provides four-wheel drive with positive traction control for demanding outdoor jobsites.

Folding rails and full-height swing gate.
Single slide-out extension deck.
AC power to platform.
Diamond plate platform deck.
Electronic horn.
Lanyard attachment points.
Platform control guard.
Platform load sense system.
Proportional drive and lift controls.
Self-closing entry gate.
Descent, tilt, and motion alarm.
Dual LED flashing beacons.
Dual wheel multi-disc brakes.
Foam-filled rough terrain tires.

Auto-leveling hydraulic outriggers.
Air line to platform.
Lift Connect telematics.
Lift Connect with Access Manager upgrade.
Power inverter on DC models.
High-capacity DC battery on DC models.
Cold weather package on RT models.
3kW AC generator on RT models.
Biodegradable hydraulic oil on RT models.
Cold weather hydraulic oil on RT models.
Rough terrain, foam-filled, non-marking tires.
Genie Genuine Accessories, including Lift Tools productivity tools, Lift Connect telematics, and Tech Pro Link handheld device.

Proportional drive and lift controls help operators make smoother, more controlled movements.
Full-height swing gate and self-closing entry gate provide convenient platform entry and exit.
Single slide-out extension deck gives operators extra reach without repositioning the lift as often.
AC power and available air line to the platform help keep tools accessible at height.
Folding rails help reduce stowed height for transport and storage.
Diamond plate platform deck provides a durable work surface.

Platform load sense system helps monitor load conditions.
Descent, tilt, and motion alarms help alert operators and nearby workers during operation.
Dual LED flashing beacons improve visibility on busy jobsites.
Lanyard attachment points support fall protection requirements.
Platform control guard helps protect the control box during operation.
Dual wheel multi-disc brakes support controlled stopping performance.
Electronic horn gives operators an audible alert for communicating around the work area.
Tilt sensor activation is rated at 3 degrees front-to-back and 2 degrees side-to-side.

38 ft 8 in maximum working height.
32 ft 8 in maximum platform height.
1,000 lb platform lift capacity.
300 lb extension deck capacity when extended.
Driveable at full platform height.
5 ft slide-out extension deck expands the working area.
83 in inside turning radius helps maneuverability on the jobsite.
9.5 in center ground clearance helps the lift travel over rougher terrain.
DC model features a 48V DC drive system with sealed AC drive motors and 35% gradeability.
RT model features diesel power, four-wheel drive, positive traction control, and up to 40% gradeability.
RT model includes a 24.8 hp Kubota diesel engine.
Auto-leveling outriggers provide up to 5.3 degrees front-to-back and 11.7 degrees side-to-side leveling capability when equipped.

On-board diagnostic system with battery charge indicator on DC models helps simplify troubleshooting and monitoring.
Tech Pro Link connector supports service diagnostics and maintenance workflows.
Lift Connect telematics can help track machine data and usage.
RT model includes a swing-out engine tray for improved service access.
Sealed AC drive motors on DC models help reduce exposure to jobsite debris and moisture.

Construction.
Facility maintenance.
Installation work.
Outdoor jobsites.
Indoor applications requiring emissions-free operation.
Warehousing and industrial facilities with firm, level surfaces.
Jobsites with dirt, sand, mud, or uneven ground conditions.
